PH13-8Mo
DESCRIPTION
Grade 13-8Mo (UNS S13800) is a martensitic precipitation-hardening stainless steel with excellent strength, toughness and good corrosion resistance. It is a through-hardening alloy, which allows it to be used with large cross section. Good transverse toughness properties can be achieved by precise chemical composition control, low carbon content and double remelting(VIM+VAR). 13-8Mo offers a high level of mechanical properties under severe environmental condtions.
APPLICATION
Common applications for steel 13-8 include: aircraft components, food processing, oil&gas,
pumps and valves, fasteners,etc. ·
KEY FEATURES
①.Excellent strength and toughness
②.Good corrosion resistance
③.Good transverse strength
PARAMETER
Common Trade Names for Reference:
AISI 632, XM-13, XM13, AMS 5629, AMS 5864, ASTM A693, ASTM A564,DIN 1.4534
Chemical Composition, (%)
|
UNS No. |
Type |
C |
Mn |
Si |
Cr |
Ni |
Al |
Mo |
|
S13800 |
XM-13 |
0.05 |
0.20 |
0.10 |
12.25-13.25 |
7.5-8.5 |
0.90-1.35 |
2.0-2.5 |
Physical Properties
|
Density |
Modulus of Elasticity |
Melting Point |
|
7.76 g/cm3 |
28.3x10?psi (195 GPa) |
1404–1440°C |
Heat Treatment:
|
Solution Heated |
PH 13-8 steel is solution heat treated by heating to 1700±25℉（925±15℃), holding for 15-30 minutes at temperature, followed by air cool as required to below 90℉(32℃） |
|
Aging-Hardening |
Precipation-hardening(aging) is conducted at a variety of temperatures from range 900-1150℉(510-621℃). See the tensile property in details. |
Minimum Tensile Properties( after age-hardening heating)
|
Condition |
Testing orientation |
Tensile strength,MPa |
Yield strength at 0.2% offset,MPa |
Elongation in 50mm,% |
Reduction area, % |
|
H950 |
Longtitudinal |
1515 |
1415 |
10 |
45 |
|
|
Transverse |
1515 |
1415 |
10 |
35 |
|
H1000 |
Longtitudinal |
1415 |
1310 |
10 |
50 |
|
|
Transverse |
1415 |
1310 |
10 |
40 |
|
H1025 |
Longtitudinal |
1280 |
1210 |
11 |
50 |
|
|
Transverse |
1280 |
1210 |
11 |
45 |
|
H1050 |
Longtitudinal |
1210 |
1140 |
12 |
50 |
|
|
Transverse |
1210 |
1140 |
12 |
45 |
|
H1100 |
Longtitudinal |
1035 |
930 |
14 |
50 |
|
|
Transverse |
1035 |
930 |
14 |
50 |
|
H1150 |
Longtitudinal |
930 |
620 |
14 |
50 |
|
|
Transverse |
930 |
620 |
14 |
50 |
SPECIFICATION
Sheet /Plate/Strip, Bar/Rod, Forgings
SIZE RANGE
Sheet/Strip---Thickness 0.10mm~0.50mm,width10.0~210.0mm, Condition:cold rolled,bright
Plate---Thickness 3.5~40.0mm,width≤300mm, Condition:cold rolled,hot rolled
Bar---Dia 8.0mm~Dia 32.0mm,length≤2000mm, Condition:hot rolled,burnished
Forgings---Dia 32.0mm~Dia 150.0mm,length≤1000mm, Condition:hot forging,peeled,turned
